Service Reference Manual
UNIT TEAR DOWN
3-3
SRM-HW/HWC 8/99
Figure 3-1
INDUCED DRAFT BLOWER/COMBUSTION BLOWER
HEATING SECTION
CONTROL SECTION
COOLING SECTION
HEAT EXCHANGER
VESTIBULE PANEL
BURNER ACCESS PANEL
FILTER ACCESS DOOR
PLATE MOUNTING
SCREWS
BURNER TRAY
GAS VALVE
FRONT HEAT
SECTION PANEL
