86341750 APEX GTX
Heat Exchanger-Cores
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86318840
1
ASSY, HEATER CORE COPPER, GT
2
86313690
3
GASKET, HEATER CORE COVER
3
86274750
18
SCR, 1/4-20 X 3/4 HHCS
4
86270330
18
FLATWASHER, 1/4
5
86182190
6
GROM, 1/2 ID X 1-1/8 OD
6
86181400
2
FTTG, BRB 3/8P x 5/8H BR
7
86010780
18
WASHER, 1/4 SPLIT
8
86180240
1
ELL, ST 3/8 45DEG BR
9
86180220
6
ELL, 3/8 BR
10
86177700
4
CONN, 3/8P X 1/2T BR
11
86177060
2
CLAMP, HOSE, #8 SST
12
86051230
1
PLATE, HTR CORE CVR FRT, STL
13
86051220
2
PLATE, HTR CORE CVR, STL
14
86043150
2
ASSEMBLY, HEATER CORE SS
