20
Operations
Technical Specifications
ITEM DIMENSION/CAPACITY
Engine speed - GAS MODELS
2740 rpm (high speed) Water Pump ON
850 rpm (idle speed) Water Pump OFF.
Engine speed - DIESEL MODELS
2650 rpm (high speed) Water Pump ON
1300 rpm (idle speed) Water Pump OFF.
Vacuum pump rpm - GAS MODELS 3100 rpm
Vacuum pump rpm - DIESEL MODELS 2600 rpm
Solution pump rpm 965 - 1000 rpm
Water flow rate 4.15 GPM (maximum)
Solution pump pressure 1200 PSI (maximum)
Vacuum relief valve 13" Hg
Waste tank capacity 60 gallons / 100 gallons
Console weight 910 lbs.
Console weight (with 60 gallon waste tank &
waste tank accessories) 1130 lbs.
(1565 lbs. If waste tank is full)
Console weight (with 100 gallon waste tank &
waste tank accessories) 1140 lbs.
(1765 lbs. If waste tank is full)
TORQUE VALUES
Engine hub
300 inch lbs 25 foot/lbs
Vacuum pump hub 300 inch/lbs 25 foot/lbs
Engine rear pulley 360 inch/lbs 30 foot/lbs
86341750 APEX GTX
