86341750 APEX GTX
Solution Pump
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86279510
5
WASHER, 3/8 X 1 FLAT NP
2
86273420
1
SCR,CAP 3/8-16X3 ALL THD
3
86273330
1
SCR, CAP 1/4-20 X 2.75 HXHD
4
86270330
2
FLATWASHER, 1/4
5
86191440
1
PUMP, CHEM, PULSE, GP
6
86191400
1
PUMP,ASSY, GEN, 4.5GPM, APEX
7
86190540
1
PLUG, 1/4T BR
8
86184550
1
HOSE, 3/16 X 20-1/2
9
86181370
1
FTTG, BRB 1/2P x 3/4H BR
10
86180410
1
ELL,3/8Px1/2T BR
11
86180360
1
ELL, 1/8P X 1/4T BR
12
86180340
1
ELL, 1/4P X 1/4T BR
13
86179920
1
EL, 90DEG 1/8 X 5/16HB
14
86177210
1
CLMP, CABL 7/16ID 1/4BLT
15
86177020
1
CLAMP, HOSE #12 SST
16
86176990
1
CLAMP, HOSE #4 SST
17
86371990
2
BELT,BANDO AX38 PWR KING COG
18
86057150
2
STRAP, WTR PMP HOLDDOWN
19
86046150
1
BRKT, WTR PMP MTG
20
86005770
4
NUT, 3/8-16 HEX NYLOCK
21
86005730
2
NUT, 3/8-16 HEX
22
86005680
1
NUT, 1/4-20 HEX NYLOCK
23
86195100
1
VALVE CAP, 303 SST, INLET
24
86189290
2
O-RING, DURO,.862ID X .103CS
25
86195110
2
VALVE KIT, ASM, CHEM, PULSE PUMP
26
86173440
1
O-RING, 1-5/8OD X 1-3/4 OD/40D VITON
27
86249220
1
PLASTIC DISC
REPLACE
TOGETHER
28
86179500
1
DIAPHRAGM, CHEM PUMP
29
86194630
1
PULSE PUMP, TOP COVER INLET
30
86191340
1
PULSE PUMP, BODY
31
86173620
1
ADAPTR, PULSE PMP, GEN PUMP
32
86195120
1
VALVE CAP, 303 SST, OUTPUT
33
86192920
1
SPACER CAP, 303 SST, OUTPUT
34
86271970
4
NUT, 3/8 PUSH PLATE
35
86277300
4
SCR, M10-1.5 X 20MM SHCS PLTD
36
86279500
4
WASHER, M10 SPLIT
37
86350880
1
KEY, GP (INTERPUMP) CLUTCH
38
86350920
1
ADAPTER, CLUTCH
39
86350890
1
CLUTCH, HTS2215S & HTS2016S
-
86282770
1
LOOM, 1/4 HI TMP X 10
WIRE COVER
-
86265780
1
CONN, BULLET M (.156)
NOT SHOWN
