86341750 APEX GTX
Helicoil
WHEN REPLACING COIL KIT, THE O-RING SEAL 86344980 MUST ALSO BE REPLACED TO
MAINTAIN SEAL INTEGRITY.
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86344980
1
O-RING, HELICOIL
2
86342090
1
BRKT, HELICOIL MTG
3
86342080
1
SHELL, FRONT, HELICOIL
4
86342070
1
SHELL, REAR, HELICOIL
5
86278910
24
WASHER, 3/8 X 7/8 FLAT SS
6
86276430
8
SCR, 3/8-16 X 1.75 HHCS SS
7
86274010
4
SCR, 3/8-16 X 2.00 HHCS SS
8
86271930
12
NUT, 3/8-16 HEX NYLOCK SS
9
86191900
2
RNG, LOCK, MNFLD, HE
10
86188980
2
NUT,1-3/4-12HXHD HE
11
86182370
2
GSKT,MNFLD HE
12
86370590
1
KIT, HELICOIL W/GASKETS
13
86369640
2
WASHER, BACKING, MNFLD HE
