Prochem Apex GTX User Manual
Page 87
85
86341750 APEX GTX
Vacuum Pump
* SEE SERIAL NUMBER PAGE
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86350410
1
WASHER, VAC REL VLV, 408 VAC
2
86340090
1
NIP, VAC EXH OUTL, 408
3
86353020
1
HOSE, FLEX, BLWR TO MFLR, 408
4
86337090
1
BRKT, BLOWER MTG, AGT
5
86279510
19
WASHER, 3/8 X 1 FLAT NP
6
86274660
2
SCR, 3/8-16 X 1.5 HHCS GR5 PLT
7
86275190
4
SCR, 3/8-16 X 1.25 HHCS SS
8
86274000
2
SCR, 3/8-16 X 3 HHCS GR5
9A
86273440
3
SCR, MACH 5/16-18 X 1" GR8
GAS
9B
86277750
3
SCR, 3/8-16 X 1.25 HHMS GR8 PL
DIESEL
10
86273420
2
SCR,CAP 3/8-16X3 ALL THD
11
86273320
1
SCR, CAP 7/16-14X4 HXHD
12
86271070
2
NUT, 7/16-14 HEX
13
86193230
1
SPRING, VAC REL VLV
14A
86191320
1
PULLEY, BLOWER, 2TB64
GAS
14B
86191110
1
PULL, 2TB74 PERF 805
DIESEL
15A
86185390
1
HUB, P1 X 1-1/4
GAS
15B
86185410
1
HUB, Q1 X 1-1/4
DIESEL
16
86180610
1
ELL, VAC REL VLV
17
86180370
2
ELL, 1/8P X 1/4 POLY BR
18
86179590
1
DIAPHRAGM, VAC REL VLV
19
86177070
2
CLAMP, HOSE #60 3.3125/4.5, SST
20
86175390
1
BLWR, TRI-FLOW, 4L TI 408
21A
86361480
2
BELT, BANDO HDPF 5480
GAS
21B
86361490
2
BELT, BANDO HDPF 5500
DIESEL
22
86010790
10
WASHER, 3/8 SPLIT
23
86005770
2
NUT, 3/8-16 HEX NYLOCK
24
86005730
4
NUT, 3/8-16 HEX
25
86049230
1
KEY, 1/4 SQ X 1.88
26
86371950
2
BRKT, BLOWER MGT
27
86006740
8
SCREW, 3/8-16 X 1 HHCS STL GR5 ZNPLT
NP
28
86371970
1
BLWR, LOW NOISE, DUAL SPLASH
1*
29
86185320
1
HUB, P1 X 7/8
1*
GAS
30
86373380
1
PULLY, 2TB56
1*
GAS
31
86371940
1
BRKT, BLOWER ADJUSTING
1*
-
86318420
.5
OIL, TUTHILL (QUART)
NOT SHOWN
-
86269820
1
MANUAL, INSTR, 4M TRIFLOW BLWR (GD)
NOT SHOWN
-
86368270
1
VENT PLUG, 3/8" NPT, 5L359
NOT SHOWN
-
86321390
1
MANUAL
NOT SHOWN
-
86189090
.1
OIL, AEON PD-XD (28G47SUTORBILT)
NOT SHOWN
