6
GETTING STARTED
8 Pin Mini-DIN
Display Screen
Inlet Connection Port
Outlet Connection Port
shown with Plug
Power Jack
P-Series Pressure Gauge
Control Valve
Inlet Connection Port
Flow Direction Arrow
Outlet Connection Port
PRESS
PSIA
PC-Series Pressure Controller Shown with Standard Upstream Valve
Inlet Connection Port
Outlet Connection Port
PCR-Series Pressure Controller
Control Valve
