HDC-3x Series SDK (Linux)
Page 16
5 Video scale (320x240)
NOTE:
The video scale support
1080(60i) -> 480(60i)
1080(59.94i) -> 480(59.94i)
1080(50i) -> 480(50i)
1080(60i) -> 320x240(30p)
1080(59.94i) -> 320x240(29.97p)
1080(50i) -> 320x240(25p)
720(60p) -> 480 (60i)
720(59.94p) -> 480 (59.94i)
720(50p) -> 480 (50i)
720(60p) -> 320x240(30p)
720(59.94p) -> 320x240(29.97p)
720(50p) -> 320x240(25p)
Step 17: Type Z to go back to the sub-menu of the encode setting.
fmb-0?>z
< Encode settings - Sub menu >
‘Z’<-~~~~~~~~
Select following number. (Current settings)
1 Output port setting (File video1.mpg)
2 Video resolution setting (1920x1080_59.94p)
3 Video bitrate setting (CBR, 6000kbps)
4 Audio format (MPEG1L2, 256kbps)
5 Video scale (Not Use)
fmb-0?>
