Analog
HDC-4x Series Video Capture Card
A.1.9 VGA Input, SW=8
Encode Decode
Rotary
Switch
Input Resolution (VGA)
HDCapture Application
Selection (Encode)
Capture (Record)
File Resolution
Output Display
(Bypass Output)
HDCapture Application
Selection (Decode)
Output Display
(Decode Output)
8 640x350 85Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 640x400 85Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 720x400 85Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 640x480 60Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 640x480 72Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 640x480 75Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 640x480 85Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 800x600 56Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 800x600 60Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 800x600 72Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 800x600 75Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 800x600 85Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 848x480 60Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 1024x768 60Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 1024x768 70Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 1024x768 75Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 1024x768 85Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
8 1152x864 75Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
