Analog
HDC-4x Series Video Capture Card
A.1 Supported Input Resolution and Video Format
The following tables list the input resolution supported by the HDC-4x Series and the corresponding video format to choose in the
HDCapture application.
A.1.1 VGA Input, SW=0
Encode Decode
Rotary
Switch
Input Resolution (VGA)
HDCapture Application
Selection (Encode)
Capture (Record)
File Resolution
Output Display
(Bypass Output)
HDCapture Application
Selection (Decode)
Output Display
(Decode Output)
0 640x350 85Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 640x400 85Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 720x400 85Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 640x480 60Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 640x480 72Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 640x480 75Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 640x480 85Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 800x600 56Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 800x600 60Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 800x600 72Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 800x600 75Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 800x600 85Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 848x480 60Hz 1280x720 60p 1280x720 60p Full screen 1280x720 60p Full screen
0 1024x768 60Hz 1920x1080 60p 1920x1080 60p Full screen 1920x1080 60p Full screen
