Analog
HDC-4x Series Video Capture Card
Page 15
6 Analog Full screen 720p
7 Digital Full screen 720p
8 Analog Full screen 1080p
9 Digital Full screen 1080p
*A~F modes are not available
Table 2-2: HDC Video Capture Card Models
The phrases used in the Table 2-2 are explained below:
ƒ Mode: the number on the rotary switch
ƒ EDID: the video input signal. Analog (VGA EDID) or Digital (DVI EDID). The
optional DVI to VGA adapter is needed for the VGA connection.
ƒ Display
o Full screen: scale up the original file to full-screen size
o Dot-by-dot: display the exact resolutions of the original file.
o Keep aspect ratio: scale up the original file, but keep the aspect ratio
ƒ Resolution
o 720p or 1080p: the resolution can be either 720p or 1080p resolution
depending on the video input resolutions.
o 720p: the resolution is 720p no matter what the input resolution is.
o 1080p: the resolution is 1080p no matter what the input resolution is.
NOTE:
To change the rotary switch setting, please turn off the system first.
