HDC-4x Series Video Capture Card
Page 3
1.3 Features
Some of the HDC-4x Series video capture card features are listed below.
ƒ DVI-I input channel up to 1920x1080@60p
ƒ Encoding or decoding with 1920x1080@60p or 1280x720@60p (per channel)
ƒ Pass through for transmitting uncompressed video up to 1080p resolution
ƒ Capture or record HD video in H.264 format
ƒ Playback the recordings on DVI-I monitor or television
ƒ Reduce the amount of hard disk space needed by real-time H.264 recording
compression capability
ƒ Low power consumption
ƒ Software development kit (SDK)
1.4 Connector Overview
The following sections introduce the two models of the HDC-4x Series.
NOTE:
The other connectors, jumpers and interfaces on the board not
specified below are for R&D diagnostic purposes and should not be
used by the end user.
1.4.1 HDC-401
The HDC-401 comes with one DVI-I input connector and one DVI-I output connector. A
PCI edge connector on the bottom of the capture card enables the HDC-401 to interface
with a motherboard.
