Analog
HDC-4x Series Video Capture Card
A.1.6 DVI Input, SW=5
Encode Decode
Rotary
Switch
Input Resolution (VGA)
HDCapture Application
Selection (Encode)
Capture (Record)
File Resolution
Output Display
(Bypass Output)
HDCapture Application
Selection (Decode)
Output Display
(Decode Output)
5 640x350 85Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 640x400 85Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 720x400 85Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 640x480 60Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 640x480 72Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 640x480 75Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 640x480 85Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 800x600 56Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 800x600 60Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 800x600 72Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 800x600 75Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 800x600 85Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 848x480 60Hz 1280x720 60p 1280x720 60p Keep aspect 1280x720 60p Keep aspect
5 1024x768 60Hz 1920x1080 60p 1920x1080 60p Keep aspect 1920x1080 60p Keep aspect
5 1024x768 70Hz 1920x1080 60p 1920x1080 60p Keep aspect 1920x1080 60p Keep aspect
5 1024x768 75Hz 1920x1080 60p 1920x1080 60p Keep aspect 1920x1080 60p Keep aspect
5 1024x768 85Hz 1920x1080 60p 1920x1080 60p Keep aspect 1920x1080 60p Keep aspect
5 1152x864 75Hz 1920x1080 60p 1920x1080 60p Keep aspect 1920x1080 60p Keep aspect
