39
8-6 Error List
As long as the RC Data Input Pendant is connected, this display will show the content of the
controller error.
(1) RC Data Input Pendant error list
Displays the error having occurred after the RC Data Input Pendant connection (PORT ON).
Select the displayed item using the Return key or keys.
Change the list number using the keys.
Error list totaled 30 (List No. 0 – 29).
RC Data Input Pendant Error List
Slct Mode/M2 A. 00
* Err List
Displays the error code number. Err List List Page 0
Err No. 0E8
Displays the error name. Err List List Page 0
A, B disconnect
Displays axis number in which the error occurred. Err List List Page 0
Axis No. 00
Displays how many minutes ago the error occurred.
Err List List Page 0
1 Min
Slct Mode/M2 A. 00
* Err List
Press the key once to return to the Mode
Select Screen.
In the Mode Select Screen, using the keys,
select Error List and then, press the Return key.
