14
8-3 Operation Mode Selection
RCP, RCS, E-Con, RCP2 and ERC will be displayed as T2.
PCON, SCON, ACON and ERC2 will be displayed as M2.
“* TP Operation Mode” will not be displayed for RCP, RCS,
E-Con, RCP2, and ERC.
For the modes, select one of the 6 options as it appears on the above screen.
To select, move the keys to the mode desired and confirm using the Return key.
Slct Mode/M2 A. 00
* Edit/Teach
Slct Mode/M2 A. 00
* Monitor
Slct Mode/M2 A. 00
* Error List
Slct Mode/M2 A. 00
* User Parmameter
Slct Mode/M2 A. 00
* TP Op Mode
Display screen
Mode Select
Edit/Teach
Monitor
Error List
User
Parameter
User
Adjustment
TP Operation
Mode
Slct Mode/M2 A. 00
* User Adjustment
RCP, RCS, E-Con, RCP2,
and ERC will not be
displayed.
