Intel
®
Server System SR1500AL User’s Guide
5
Hard Drive Controller
Options
•
Three ESB2 3Gb/s SATA ports (Note: 6 SATA connectors are
on the server board; only 3 SATA connectors are used in the
system)
•
Up to three SAS drives are supported (SR1500ALSAS only)
•
Intel
®
Embedded Server RAID Technology II with SW RAID
levels 0/1/10
•
Optional support for SW RAID 5 with enablement key
Peripherals
•
Slimline bay for IDE optical drive
•
PCI riser card bracket
Control Panel (dependent
on option selected)
•
Standard control panel
•
Intel
®
Local Control Panel
LEDs and displays
(dependent on option
selected)
With standard control panel:
•
NIC1 Activity
•
NIC2 Activity
•
Power / Sleep
•
System Status
•
System Identification
•
Hard Drive Activity
With Intel
®
Local Control Panel:
•
NIC1 Activity
•
NIC2 Activity
•
Power / Sleep
•
System Status
•
System Identification
•
Hard Drive Activity
•
LCD Display
Power Supply
Single 600 W power supply module
Fans
•
Six 4-pin fan headers supporting two processor fans, and four
system fans
•
Two non-redundant fans in power supply
USB
•
Two front panel USB ports
•
One internal USB header providing two USB ports
System Management
Intel
®
System Management Software
Table 2. Intel
®
Server System SR1500AL Feature Summary
Feature
Description
