4G9 ENGINE (E–W) –
Water Pump and Water Hose
11A-7-5
PWEE9502-B
E
Nov. 1996
Mitsubishi Motors Corporation
Revised
INSTALLATION SERVICE POINTS
"
A
A
WATER PUMP INSTALLATION
(1) Apply 3 mm diameter of Form-In-Place Gasket (FIPG)
to the location shown in the illustration.
Specified sealant:
Mitsubishi Genuine Part No.MD970389 or
equivalent
"
B
A
WATER INLET PIPE
(1) Replace the O-ring of the water inlet pipe DRIVE> or water pipe Caution Never apply any oil or grease to the O-ring. 2. Secure the water pipe after the thermostat case " C A THERMOSTAT CASE INSTALLATION (1) Apply 3 mm diameter of Form-In-Place Gasket (FIPG) to the location shown in the illustration. Specified sealant: Mitsubishi Genuine Part No.MD970389 or " D A THERMOSTAT INSTALLATION (1) Install the thermostat so that the jiggle valve is facing straight up. " E A WATER OUTLET FITTING INSTALLATION (1) Apply 3 mm diameter of Form-In-Place Gasket (FIPG) to the location shown in the illustration. Specified sealant: Mitsubishi Genuine Part No.MD970389 or PWEE9502-K E Jun. 2002 Mitsubishi Motors Corporation Revised Jiggle valve
apply water to the O-ring to make installation easy.
1.
has been installed.
equivalent
equivalent
