4G9 ENGINE (E–W) – Specifications
11A-1-6
Items Nm
Fuel system and emission system
Breather tube 21
Fuel pump 18
Carburetor 17
EGR valve 21
Cover 12
Fuel return pipe 9
Delivery pipe 12
Fuel pressure regulator 9
Throttle body stay 23
Throttle body stay <4G94> 24
Throttle body 19
Throttle cable bracket 19
Stay 24
Harness bracket 11
Vacuum hose and pipe assembly (Flange bolt) 11
Vacuum hose and pipe assembly (Bolt and
washer assembly) 9
Vacuum hose and pipe assembly 10
Solenoid valve assembly 9
Throttle body and EGR system (GDI)
Air intake resonator 9
Intake manifold stay (M8) 20
Intake manifold stay (M10) 30
Water hose clamp 13
Water pipe 11
Throttle body 18
Throttle body stay
24
Throttle body stay 18
EGR valve (Bolt and washer assembly) 18
EGR valve (Flange bolt) 24
Engine hanger 18
EGR valve support bolt 18
EGR valve support nut 23
Air by-pass valve 9
PWEE9502-I
E
Mar. 2001 Mitsubishi Motors Corporation Revised PWEE9502-K
E
Jun. 2002 Mitsubishi Motors Corporation Revised
