1 GENERAL INFORMATION
1.1 INTRODUCTION
The FURUNO FM-4000 is a Marine VHF Radiotelphone designed for use in
the frequency range of 156.025 to 163.275 MHz. The FM-4000 can be pow-
ered with 11 to 16 VDC power and has a switchable RF output power of 1 Watt
or 25 Watts.
The FM-4000 operates on all currently allocated marine channels. Channels
are switchable for use with USA, International, or Canadian regulations. Emer-
gency CH16 can be immediately selected by pressing the red [16/9] key. NOAA
weather channels can also be accessed immediately by pressing the [WX]
key.
The FM-4000 incorporates DSC (Digital Selective Calling) Class D facilities
which comply with ITU-R M.493-11 (DSC Class D). Class D operation pro-
vides continuous watch on DSC CH70 even if the radio is receiving a call.
Two Remote MICs (CMP30, remote-control speaker/microphone with display)
are available.
The main features are
z Commercial grade ITU class D DSC transceiver
z Superior receiver performance (80 dB rejection)
z 30W LoudHailer complete with listen-back and four fog horns, bells, and
whistle
z 2.2-inch internal speaker produces clear, loud audio
z 2.58” x 1.28” dot matrix display
z Alphanumeric keypad allows direct entry of channel numbers or selection
of most used functions
z NAV mode displays latitude/longitude, position, time, SOG, COG
Ú
z Oversized rotary selector, volume and squelch knobs
z Programmable scan, selectable priority scan, and dual watch
z One-button access to CH16 and CH9
z Treble and bass audio tone control
z Two inputs for optional Remote MIC
z Optional voice scrambler
z Multi-station intercom
z High and low voltage warnings
Ú When connected to a GPS receiver.
