NOTE:

NOTE: Hot Plug and SAS functionality requires the addition of Smart Array or HBA controller. 12 hard drive
support requires a 4-port SAS controller that supports expanders.

Internal storage capacity:

SATA Models: Up to 12.0TB (12 x 1TB Hot Plug 3.5" hard drives)
SAS Model: Up to 12.0TB (12 x 1TB Hot Plug 3.5" hard drives)

Network Controller

Network Controller:

One integrated NC105i PCI-e Gigabit NIC (embedded) (Wake on LAN and PXE capable)

Storage Controllers

Storage Controllers:

HP Embedded SATA RAID Controller (up to 4 hard drive support on base models)

Expansion Slots

Expansion Slots:

One available Low Profile x8 PCI-Express slot using a Low profile Riser.
Two Full Height/ Full Length Riser options

Option1: 2 full-length/full-height PCI-Express x8 connector slots (x4 electrical - Standard)
Option2: full-length/full-height riser with 2 PCI-X Slots(Optional)

Management

Management:

Optional HP Lights Out 100c Remote Management card with Virtual KVM and Virtual Media support (includes IPMI2.0
and SMASH support)

USB Ports

USB Ports:

Seven USB ports (2) front, (4) rear, (1) internal

Optical Drive

Optical Drive:

Support for one:

Optional Multi-bay DVD
Optional Floppy (USB only, USB key)

Power Supply

Power Supply:

750W Power Supply (Optional Redundancy Hot Plug, Autoswitching) CSCI 2007/8
1200W High Efficiency Power Supply (Optional Redundancy Hot Plug, Autoswitching) (Optional) CSCI 2007/8

NOTE:

NOTE: Climate Savers Computing Initiative, 2007-2008 Compliant

Form Factor

Form Factor:

2U rack models

Deployment/Serviceability

Deployment/Serviceability:

Tooled access to all system components for easy in rack serviceability
Customer Self Repair (CSR): HP products are designed with many CSR parts to minimize repair time and allow for
greater flexibility in performing defective parts replacement

Warranty

Warranty:

This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP
Authorized Channel Partners. Hardware diagnostic support and repair is available for one year from date of purchase
(3-1-1 warranty in AP and Brazil). Support for software and initial setup is available for 90 days from date of purchase.
Enhancements to warranty services are available through HP Care Pack services or customized service agreements.
SATA hard drives have a one-year warranty.

NOTE:

NOTE: Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year (3-1-1-in AP and Brazil) Onsite support (3-1-1-in
AP and Brazil) with next business day response. Warranty repairs may be accomplished through the use of Customer
Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement.
A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts
are also designed for easy replacement but may involve added complexity. Customers may choose to have HP replace
Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is
available at:

http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

QuickSpecs

HP ProLiant DL180 Generation 5 (G5)

Overview

DA - 12903 Worldwide — Version 10 — July 14, 2008
