3800g User’s Guide 12 - 1
12
Product Specifications
3800g Product Specifications
Parameter Specification
Dimensions (Typical):
Height 5.9 inches (15 cm)
Length 4.4 inches (11.2 cm)
Width 3.1 inches (7.9 cm)
Weight 5.6 ounces (160 g)
Light Source 630 nm visible red LED
Scan Rate 270 scans per second in most usages
Skew Angle
±65 degrees
Pitch Angle
±65 degrees
Horizontal Velocity 20 inches (50 cm) per second
Scan Contrast 20% minimum
Voltage Requirements 4.5 to 12VDC at imager
Current Draw (Max): Scanning Standby Inrush
3800GX4E @4.5-5.5Vdc 235mA 87mA 380mA
3800GX5E @4.5-12Vdc 126mA 50mA N/A
Temperature Ranges:
Operating 32
° F to +122° F (0° C to +50° C)
Storage -40
° F to +140° F (-40° C to +60° C)
Humidity 0 to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 5 feet
(1.5 m) to concrete
Vibration Withstands 5G peak from 22 to 300 Hz
ESD Sensitivity 15 kV to any external surface
Sealant Rating IP41
Agency Compliance
FCC Class B, CE EMC Class B, CE Low
Voltage Directive, IEC60825-1 LED Safety; Class 1,
UL, cUL, C-Tick, NOM, USB Certified
