TROUBLESHOOTING
88
for use in SP recording only.
Picture bends at the top of the TV
screen. TV receiver is older type. It needs
to be modified to work properly with
another cassette.
Tape is damaged. Try another
cassette.
Color of your TV screen is too
bright, too faint or change. TV set has VIR circuit. Turn off
during playback.
CLEANING THE INSIDE OF THE ELECTRONIC VIEWFINDER
If dust or foreign matter adheres inside the viewfinder, clean it by using the following
procedure.
1. Rotate and remove eye cup.
2. Clean the picture tube face and lens. To prevent scratching, use a soft non abrasive
cloth, swab or lens cleaning paper.
3. Align the reference mark and rotate the eye cup in the direction of arrow.
