ATTACHING THE TELEPHOTO OR WIDE ANGLE LENS
44
ATTACHING THE TELEPHOTO OR WIDE ANGLE LENS
1. To remove the lens hood, turn the focus ring to the 0.7 meter position, then turn it
counterclockwise as shown in the figure.
NOTE: To attach the lens hood, align the convex section of the lens hood and the concave
section of the lens, then turn the focus ring to the infinity (
) mark and turn it clockwise.
2. Remove both caps of the telephoto or wide angle lens.
3. Attach the lens adaptor (optional) to the lens and then screw the lens into the threads
on the front of camera/recorder lens assembly.
NOTE: Auto focusing will not operate correctly when the telephoto or wide angle lens is
attached to the video camera/recorder.
