Hustler Turf ATZ 928150 - Manual (Page 63)

108604 10/08 8-15
60" Rear Discharge Deck Pulley Assembly
NOTES:
1. Torque to 118 ft. lbs.
2. Torque to 65-75 ft. lbs.
3. See “60" Rear Discharge Belt Routing and Tensioning” on page 9-6 for
belt tensioning.
4. See “Spindle Assembly–796235” on page 8-16 for breakdown.
5. See “Spindle Assembly–796680” on page 8-17 for breakdown.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY. DESCRIPTION
1 795781 795781 1 60" REAR DISCHARGE DECK BELT
2 110411 110411 1 PULLEY COVER, RH,60"
3 110412 110412 1 PULLEY COVER, LH,60"
4 794446 794446 1 CS .625-11X1.500 HX G5 Z
5 028118 028118 7 FW .62 X 1.00 X .134 ZN
6 796714 796714 5 6" HB IDLER PULLEY RD
7 781567 781567 1 NT .500-13 HX G8 ZY NL
8 767962 767962 13 FW .531 X 1.063 X .090 SAE HD ZN
9 770867 770867 2 BUSHING, PLAS .750X1(FS)
10 109549 109549 1 BUSHING, IDLER PIVOT
11 600296 600296 1 DECK IDLER SPACER
12 109948 109948 1 IDLER ARM W/A
13 601779 601779 1 IDLER SLIDE UHMW
14 797910 797910 2 CS .312-18X1.50FLT SH ZY
15 704759 704759 1 FW .500X 1.250X.075 ZNY
16 781302 781302 1 IDLER SPRING
17 259812 059931 1 DECK LIFT CHAIN (13 LINKS)
18 016972 016972 4 NT .625-11 HX G5 ZNYC
19 016527 016527 15 CS .500-13 X 1.00 HX G5 ZN
20 752386 752386 3 FW .510 X 1.75 X .18 ZN
21 770842 770842 3 B-SECTION PULLEY
22 792002 792002 4 5/16-18 X 3/4" MALE KNOB
23 782474 782474 5 CW .631 X 2.250 X .187 PNT
24 783738 783738 2 CS .625-11X3.00 FULL HX G5 ZN
25 796680X 796680 1 REAR DISCHARGE DECK SPINDLE ASSEMBLY
26 796235X 796235 2 DECK SPINDLE ASSY
27 212472 212472 3 KEY 1/4 SQ X 1.00 LONG
28 600901 600901 2 BLADE, F20.50"-L-F-CW
29 795633 795633 1 BLADE, F20.50"-L-F-CCW
30 796722 796722 1 CS .625-11 X 3.00 LH HX G
31 029934 029934 2 CS .625-11 X 3.00 HX G5 ZNYC
32 768523 768523 1 FW .343X.687X.051/.080H
33 058776 058776 1 NT .312-18 HXZY NL
