108604 10/08 11-3
Seat Installation
NOTES:
1. Must pivot freely.
2. Torque to 48 ft.-lbs.
3. Service parts available for Michigan suspension seat:
ITEM
NO.
SERVICES
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 792051 792051 1 SUSPENSION SEAT
2 784140 784140 1 SEAT BELT
3 797076 797076 4 CS .437-20 X 1.00 HX G8 ZNYC
4 728147 728147 2 FW .468 X 1.00 X .090 HT T ZNYC
5 746131 746131 2 SPACER, .493 X .675 X .250
6 036236 036236 1 CS .312-18X1.000 HX G5
7 078386 078386 2 FW .510 X 1.750 X .18 ZNYC
8 110686 110686 1 TILTSEAT PIVOT TUBE
9 000331 000331 2 BLACK CABLE TIE
10 086660 086660 3 NT .375-16 HX LK NY
11 767954 767954 6 FW .406 X .812 X .060 SAE HD ZN
12 724716 724716 1 FIBER WASHER
13 350421 350421 1 SEAT PAN STOP
14 036244 036244 1 CS .375-16 X 1.00 HX G5 ZNYC
15 108291 108291 1 SEAT PAN
16 357384 357384 1 ROPS LATCH
17 768523 768523 6 FW .343 X .687 X .051/.080 HD ZN/Y
18 034272 034272 5 NT .312-18 HX G5 ZN
19 783910 783910 1 ROPS LATCH TORSION SPRING
20 781880 781880 2 BUMPER
21 080358 080358 1 GM .50 X 1.00 X .75 X .12 GROMMET
22 052860 052860 2 CS .375-16 X 1.25 HX G5 ZNYC
23 781567 781567 2 NT .500-13 HX G8 ZY NL
24 722199 722199 1 2" WIDE SCOTCH POLYURETHANE 5.55" LONG
25 601130 601130 1 ELECTRIC LINEAR ACTUATOR
26 108290 108290 1 SEAT MOUNT
27 089938 089938 1 CS .500-13X4.00 HX G5 Z
28 770867 770867 2 PLASTIC BUSHING .750X1(FS)
29 601053 601053 2 SEAL RELAY W/BRACKET
30 601647 601647 1 15 AMP CIRCUIT BREAKER
31 601648 601648 1 RED CIRCUIT BREAKER BOOT
32 068239 068239 1 CS .500-13X4.500 HX G5
33 601098 601098 2 CB 10-24 X .500 ZYNC
34 110677 110677 1 RELAY MOUNT BRACKET
35 601089 601089 4 RIVET .188 DIA BLK HD
36 059832 059832 2 NT #10-24 HX NL ZN
37 704932 704932 2 FW .219 X .500 X .048 ZN
38 767962 767962 4 FW .531X 1.063X.090 SAE
PART NO. DESCRIPTION
793307 SLIDE KIT
793323 KNOB KIT
793281 BACK CUSHION KI
