Page 33
108604 10/08
5-5
Fuel System Installation
NOTES:
1. Torque to 20 ft.-lbs.
2. Supplied with Item 18 (3-way fuel switch.)
3. Included with new fuel tank.
4. Fuel tank service parts not shown:
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY
DESCRIPTION
1
779306
779306
2
3.5" FUEL CAP
2
793240
793240
1
LEFT SIDE Z FUEL TANK
3
793232
793232
1
RIGHT SIDE Z FUEL TANK
4
106732
106732
1
REAR SEAT SUPPORT
5
712919
712919
12
FW .406 X 1.00 X .12 HRD ZN
6
767954
767954
3
FW .406 X .812 X .060 SAE HD ZN
7
055822
055822
12
CS .375-16 X .750 HX G5 ZN
8
000398
000398
1
CLAMP
9
036244
036244
4
CS .375-16 X 1.000 HX G5 ZN
10
045088
045088
1
HOSE CLAMP 1"
11
347989
347989
1
FUEL SHUT-OFF BRACKET
12
015818
015818
1
FUEL LINE 50” TOTAL
13
015818
015818
1
FUEL LINE 39” TOTAL
14
015818
015818
1
FUEL LINE 7” TOTAL
15
000323
000323
6
CLIP
16
705954
705954
8
CS .500-13 X 1.00 HX G5 ZN
17
767962
767962
8
FW .531 X 1.063 X .090 SAE HD ZN
18
797084
797084
1
3-WAY FUEL VALVE
000331
000331
3
BLACK CABLE TIE (NOT SHOWN)
PART NO.
DESCRIPTION
794107
1/4 ID, 3/8 OD, 1/16 WALL TUBING (25" LONG)
794081
FUEL FILTER SCREEN
785295
FLANGE GROMMET
792986
SITE-LINE FUEL FITTING
