Hustler Turf ATZ 928150 - Manual (Page 31)

108604 10/08 5-3
Kawasaki 31 HP Engine Installation
NOTES:
1. Includes mounting hardware.
2. Wires from Item 29 (ATZ 2008 Wire Harness 601555).
3. Wires from Kawasaki 31HP Wiring Harness (601561).
4. Supplied with engine.
5. Engine oil capacity, Refer to engine owner’s manual.
6. Air filter service parts:
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 601549 N/A 1 KAWASAKI 31 HP ENGINE
2 109743 109743 1 CABLES HEAT SHIELD
3 720516 720516 3 CS M8 X1.25 X 16 G10.9 HX
4 788018 788018 1 MUFFLER
5 785378 785378 1 1.50" MUFFLER CLAMP
6 601550 601550 1 MANIFOLD, 29/31 KAW
7 780841 780841 2 KAW MUFFLER GASKET
8 017004 017004 5 LW .312 MED SPRING ZN
9 782664 782664 5 NT M8-1.25 HX STAINLESS STEEL
10 029751 029751 2 CS .375-16 X 1.00 HXFLK ZNYC
11 705137 705137 4 FW .391 X 1.250 X .060 ZNYC
12 016899 016899 2 NT .375-16 HX FLK ZNYC
13 055939 055939 6 CS .250-20 X .75 HX G5 ZNYC
14 768515 768515 6 FW .281 X .625 X .051/.080 HD ZN/YL
15 109748 109748 1 HOOD SCOOP
16 783837 783837 1 ELECTRIC COOLER FAN
17 109604 109604 1 REMOTE AIR BRACKET
18 778738 778738 1 .312 WIRING CLAMP
19 768523 768523 12 FW .343 X .687 X .051/.080 HD ZN/YL
20 034272 034272 4 NT .312-18 HX G5 ZN
21 796524 796524 1 M20X2.5 OIL DRAIN VALVE
22 036236 036236 1 CS .312-18 X 1.00 HX G5 ZNYC
23 034280 034280 3 CS .312-18 X .750 HX G5 ZNYC
24 036244 036244 4 CS .375-16 X 1.00 HX G5 ZNYC
25 377994 377994 1 HEAT SHIELD, MMZ ROLLER
26 601257 601257 1 FITTING, 90 1/8NPT BRASS
27 788943 788943 1 AIR FILTER INDICATOR
28 029876 029876 1 LW .312 INT-EXT TOOTH ZN
29 601555 601555 1 XR7 COMMON WIRE HARNESS
30 601561 601561 1 WIRING HARNESS, KAWASAKI 31
31 044818 044818 4 CN ZN TIN-C7343-1420
32 047654 047654 1 CLIP
601652 MAIN AIR FILTER ELEMENT
601653 SAFETY AIR FILTER ELEMENT
