108604 10/08 5-7
Instrument Panel Assembly/Installation
NOTES:
1. Part of 601555 (Wire Harness)
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 776476 776476 1 PTO SWITCH
2 785808 785808 1 KEY SET
3 045898 045898 1 KEY SWITCH
4 000430 000430 2 SMALL/LONG WIRE TIE
5 785030 785030 1 CHOKE CABLE
6 712257 712257 1 RED INDICATOR LIGHT
7 714998 714998 2 MS #10-24 X .625 HX ZN
8 704932 704932 6 FW .219 X .500 X .048 ZN
9 769166 769166 1 HOUR METER
10 059832 059832 4 NT #10-24 HX NL ZN
11 601675 601675 1 THROTTLE CABLE
12 055947 055947 3 CS .250-20 X .500 HX G5 ZN
13 768515 768515 3 FW .281 X .625 X .051 /.080 HD ZN/YL
14 110151 110151 1 INSTRUMENT PANEL
15 601089 601089 2 RIVET .188 DIA BLK HD
16 060731 060731 2 CS 10-24X .500 HXFLK ZN
17 110152 110152 1 RELAY MODULE BRACKET
18 601554 601554 1 Z SPARK IGNITION CONTROLLER
