108604 10/08 4-7
Park Brake Assembly
NOTES:
1. Torque to 280-310 ft.-lbs. Included with wheel motor.
2. Torque to 24 ft.-lbs.
3. 783126 used on left wheel.
4. 783118 used on right wheel.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 767954 767954 12 FW .406 X .812 X .060 SAE HD ZN
2 768523 768523 8 FW .34 3X .687 X .051/.080 HD ZN/YL
3 023655 023655 2 NT .312-24 HXZY NL
4 782979 782979 2 CS .375-16 X 4.75 HX G5 ZN
5 063198 063198 4 CS 10-24 X .750 HXFLK ZN
6 781211 781211 2 PUSH BUTTON SWITCH
7 059832 059832 4 NT #10-24 HX NL ZN
8 034272 034272 4 NT .312-18 HX G5 ZN
9 054502 054502 4 NT .375-16 HX GRD 5 ZN
10 354035 354035 2 WHITE BRAKE LEVER EXTENSION
11 005116 005116 4 CS .375-16 X 1.375 HX G5 ZN
12 350397 350397 2 BRAKE LINK TURNBUCKLE
13 350330 350330 1 L.S. BRAKE PIVOT ARM
350264 350264 1 R.S. BRAKE PIVOT ARM
14 765339 765339 4 BUSHING
15 086660 086660 2 NT .375-16 HX LK NY
16 783126 783126 1 LH WHITE BRAKE ASSY
783118 783118 1 RH WHITE BRAKE ASSY
17 789321 789321 2 WHITE HUB ASSEMBLY
18 036236 036236 4 CS .312-18 X 1.000 HX G5 ZN
19 789644 N/A 2 NUT FOR WHITE MOTOR (RC28)
20 601344 N/A 2 KEY FOR WHITE MOTOR
21 712927 712927 8 FW .344 X 1.00 X .12 HRD ZNYC
22 048876 048876 8 CS .312-18 X .750 HX G8 ZNYC
