Hustler Turf ATZ 928150 - Manual (Page 53)

108604 10/08 8-5
72" Side Discharge Deck Pulley Assembly (XR7)
NOTES:
1. Torque to 118 ft. lbs.
2. Torque to 67-75 ft. lbs.
3. See “72" Side Discharge Belt Routing and Tensioning” on page 9-4 for
belt tensioning.
4. See “Spindle Assembly–796235” on page 8-16 for breakdown.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 784207 784207 1 B-SECTION BELT
2 797910 797910 6 CS .312 - 18 X 1.50 FLT SH ZNYC
3 601434 601434 2 UHMW IDLER SLIDE
4 025007 025007 1 CS .625 - 11 X 1.75 HX G5 ZNYC
5 347443 347443 1 DECK BELT IDLER GUIDE
6 028118 028118 3 FW .62 X 1.00 X .134 ZN
7 781856 781856 1 5.00" IDLER PULLEY
8 259812 059931 1 CHAIN DECK LIFT SPRING (13 LINKS)
9 781302 781302 1 IDLER SPRING
10 350884 350884 1 DECK IDLER
11 107620 107620 1 RS PULLEY COVER 72" XR7
12 107621 107621 1 LS PULLEY COVER 72" XR7
13 016972 016972 2 NT .625 - 11 HX G5 ZNYC
14 781385 781385 2 6.00" IDLER PULLEY
15 797449 797449 4 FW .650 X 1.125 X .18 ZNYCG5
16 792002 792002 4 5/16 - 18 X 3/4" MALE KNOB
17 016527 016527 3 CS .500 -13 X 1.00 HX G5 ZN
18 752386 752386 3 CW .515 X 2.25 X .204 ZN
19 538850 538850 3 DRIVE PULLEY DB-112
20 705954 705954 12 CS .500-13 X 1.25 HX G5 ZNYC
21 767962 767962 12 FW .531 X 1.063 X .090 SAE HD ZN
22 768523 768523 6 FW .343 X .687 X .051/.080 HD ZN
23 058776 058776 6 NT .312 -18 HXZY NL
24 212472 212472 3 KEY 1/4 SQ X 1.00 LONG
25 796235X 796235 3 SPINDLE HOUSING ASSEMBLY
26 798702 798702 3 BLADE, F24.50" -H-F-CW
27 782474 782474 5 CW .631 2.250 X .187 PNT
28 769257 769257 1 FW .656 X 1.250 X .250 ZNYC
29 029934 029934 3 CS .625 -11 X 3.00 HX G5 ZNYC
30 783738 783738 2 CS .625-11 X 3.00 FULL HX G5 ZN
4
