Hustler Turf ATZ 928150 - Manual (Page 51)

108604 10/08 8-3
72" Side Discharge Deck Assembly
NOTES:
1. Do not torque, Item 2 (798694 Discharge Chute) must pivot freely.
2. Includes items 7, 8, 9, and 10.
3. Service part deck includes decals (see “72" & 60" Side Discharge Deck
Decals(XR7)” on page 10-4 for listing of decals).
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 548453 108649 1 72" DECK WACRATED
2 798694 798694 1 RUBBER CHUTE ASSEMBLY
3 052860 052860 8 CS .375-19 X 1.250 HX G5 ZN
4 767954 767954 26 FW .406 X .812 .060 SAE HD ZN
5 086660 086660 14 NT .375-16 HXZY NL
6 103010 103010 1 DISCHARGE CHUTE MOUNT BRACKET
7 781708 N/A 6 CS .500-13 X 4.25 HX G5 ZN
8 767962 N/A 12 FW .531 X 1.063 X .090 SAE HD ZN
9 031997 N/A 6 ANTI-SCALP WHEEL
10 053199 N/A 6 NT .500-13 HX JAM ZN
11 781567 781567 6 NT .50-13 HX LK NY
12 005116 005116 4 CS .375-16X1.375 HX G5
13 808485 808485 4 5/16-18 THREAD RIVET NUT
14 314104 314104 1 PUSHER
15 015495 015495 2 STRAIGHT GREASE FITTING
16 103184 103184 2 REAR ANTI-SCALP BRACKET
17 025395 025395 2 CB .375-16 X 1.00 STD CD
18 808493 808493 2 3/8-16 THREAD RIVET NUT
788166 788166 6 ANTI SCALP WHEEL ASSY
3
2
