108604 10/08 6-3
Front Wheel Assembly
NOTES:
1. Apply grease to zerks (see owners manual).
2. Torque to 100 ft.-lbs.
3. Assemble with extended inner race toward item 6 (387035 Spacer, 1.07
x 1.312 x 2.793).
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 705954 705954 2 CS .500-13 X 1.25 HX G5 ZN
2 344267 344267 2 FW .510 X 2.15 X .187 SPL ZN
3 798603 798603 2 FW .515X1.65X.125 HD ZY
4 263517 263517 2 BEARING DISC
5 784223 784223 4 BEARING W/O COLLAR
6 387035 387035 2 SPACER, 1.07 X 1.312 X 2.793
7 045765 045765 2 FW 1.030 X 1.500 X.134 ZN
8 349266 349266 2 FORK
9 041475 041475 2 CS .750-10 X 9.50 HX ZN
10 025296 025296 4 FW .760 X 1.625 X .08 ZN
11 061101 061101 2 NT .750-10 HX NL ZN
12 789537 789537 2 WHEEL & TIRE ASSY
