Hustler Turf ATZ 928150 - Manual (Page 25)

108604 10/08 4-11
Steering Sub-Assembly
NOTES:
1. Includes Item 1 (781260 Steering Bar Grip).
2. Includes Item 15 (601769 Lower Handle Grip) and Item 16 (601768 End
Handle Grip)
ITEM NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 781260 N/A 1 STEERING BAR GRIP
2 348755 348755 1 STEERING BAR
3 767954 767954 16 FW .406 X .812 X .060 SAE HD ZN
4 036244 036244 4 CS .375-16 X 1.000 HX G5 ZN
5 705178 705178 6 CS .375-16 X 1.750 HX G5 ZN
6 023655 023655 2 NT .312-24 HXZY NL
7 768523 768523 4 FW .343X .687 X .051/.080 HD ZN/YL
8 348946 348946 2 STEERING ARM MOUNT
9 348888 348888 1 STEERLEVER SUPPORT LH (SHOWN)
348714 348714 1 STEERLEVER SUPPORT RH
10 781153 781153 4 BUSHING
11 781716 781716 2 SS .500-13 X 1.75 SH ZN
12 781583 781583 2 BRAKE ROD ASSEMBLY
13 086660 086660 6 NT .375-16 HX LK NY
14 348862 348862 4 STEERLEVER BUSHING
15 601769 N/A 1 GRIP, RH HANDLE LOWER
16 601768 N/A 1 GRIP, RH HANDLE END
17 053660 053660 1 RP .125DX1.000 LG ZN
18 110674 110674 1 TILT SWITCH HOUSING
19 110681 110681 1 KEY, TILT SWITCH HANDLE
20 601727 601727 1 TILT SWITCH WIRE HARNESS
21 110680 110680 1 STEERING HANDLE W/A
