Page 19
108604 10/08
4-5
Deck Lift Assembly
NOTES:
1. Apply grease to zerks (see owners manual).
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY
DESCRIPTION
1
348318
348318
1
STOP HANDLE
2
600437
600437
1
HEIGHT ADJUSTMENT STOP (½" DIA PIN)
3
783001
783001
1
DECK LIFT INDICATOR
4
704643
704643
8
NT .437-14 HX FLG ZN
5
781294
781294
7
CLIP E, 1.00 X.625X .050
6
782995
782995
2
DECK LIFT SPRING ASSEMBLY
7
015495
015495
4
STRAIGHT GREASE FITTING
8
055749
055749
3
CS .437-14X1.750 HX G5 ZNYC
9
348391
018846
4
DECK LIFT CHAIN
10
756270
756270
1
CS .312-18 X 1.50 FLTHR GR5 ZNYC
11
034272
034272
1
NT .312-18 HX G5 ZNYC
12
348458
348458
1
DECK LEVELER YOKE W/A
13
781229
781229
1
CE .750X2.25 X1.75 HEADLESS
14
781831
781831
1
CS .437-14 X 1.750 FULTH G5 ZNYC
