Page 7
07/03
P/N 211636C
7
PARTS LIST - (See Hardware Identifier)
Item Qty.
Part No.
Description
1
1
206620
Tank
2
2
203451
Wheel Axle, 13-5/8 Long
3
2
226404
Wheel, 6” (Black)
4
1
908006
Top Pole Section
5
1
908107
Middle Pole Section
6
1
908005
Bottom Pole Section
7
4
203223
Bolt, Carriage 5/16-18 x 1
8
2
206934
Large Eyebolt, 3/8”
9
1
201581
Pole Mount Bracket
10
2
203063
Nylon Insert Lock Nut, 3/8-16
11
1
206634
Rod, 1/2 x 9-1/2 Long
12
1
203099
Nut, Ny-lock, 5/16-18
13
6
203218
Washer, 5/16 Flat
14
1
202662
Bolt, Hex Head, 5/16-18 x 4-1/2 Long
15
2
200341
Bolt Cover
16
11
203100
Hex Flange Nut 5/16-18
17
1
204832
Bracket, Pole Mount
18
2
203053
Carriage Bolt, 5/16-18 x 4 Long
19
4
203232
Washer, Metal, 3/4” O.D.
20
4
201124
Lock Nut, 3/8-16
21
4
206360
Bolt, Hex Head, 3/8-16 x 2-5/8 Long
22
2
204858
Spacer, Plastic Biscuit
23
2
204857
Spacer, Metal 1/2” O.D. x 1.44 Long
24
2
204859
Cover, Pin Slide
25
1
203038
Carriage Bolt, 5/16-18 x 2-3/4 Long
26
1
204850
Pin, Locking
27
1
204853
Lanyard, Black Coil
28
1
904833
Height Adjustment Rod
29
1
204872
Label, Height Indicator
30
2
203103
Carriage Bolt, 5/16-18 x 2 Long
Item
Qty.
Part No.
Description
31
1
204803
Screw, Phillips Head
32
1
204855
Handle, Left
33
1
204856
Handle, Right
34
4
201683
Spacer, .530 I.D. x 1.5 Long
35
2
200964
Bracket, Backboard Support
36
2
200874
Spacer, Steel .402 I.D. x .5 O.D. x 1.5 Long
37
6
206244
Bolt, Hex Head, 1/2-13 x 8 Long
38
4
201642
Spacer, Plastic, .530 I.D. x .625 Long
39
7
206340
Lock Nut, Hex Head, 1/2-13
40
2
904820
Elevator Tube, Lower - Long
41
1
204837
Spring, Counter Balance
42
1
Rim
43
2
904808
Elevator Tube, Upper - Short
44
2
201682
Spacer, .530 I.D. x 1.875
45
2
900867
Plate, Triangle, (Black)
46
1
207103
Cap, Pole Top
47
1
206002
Front Cover
48
1
202856
Bolt, Hex, 1/2-13 x 4 Long
49
1
206219
Plug, Tank Cap
50
12*
201219
Net Clip, (White)
51
1
204290
Net
52
1
204444
Black Nylon Rope
53
1
203124
Stake, Tie Down
54
1
201252
Label, Height Adjustment and Moving
55
6
203309
Washer, .406 I.D. x 1 O.D. Flat
56
4*
205528
Bolt, Hex Flange, 5/16-18 x 1 Long
57
2
203452
Small Eye Bolt, 5/16-18
58
1
206990
Reinforcement Bracket
59
2
200520
Screw, #8 x 1/2
60
1
200503
Cover, Black
61
4
201681
Spacer, Plastic, .530 I.D. x .88 Long
NOTE: Hardware kit is designed for more than one style of basketball
system. Not all hardware will be used.
* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL.
WARNING: IF YOUR SYSTEM IS EQUIPPED WITH AN ACRYLIC
BACKBOARD, EXAMINE BACKBOARD FOR ANY DAMAGE THAT MAY
HAVE OCCURRED DURING SHIPMENT. CRACKS IN THE BACKBOARD
COULD RESULT IN SUDDEN BREAKAGE. IF BACKBOARD IS DAMAGED
IN ANY WAY PRIOR TO OR AFTER ASSEMBLY, CALL TOLL-FREE
NUMBER:
U.S. 1-800-558-5234; CANADA: 1-800-284-8339; http://www.huffysports.com
