22
P/N 211636C 07/03
6. Install net clips.
CLIP “ARM”
CLIP “BODY”
Insert one “arm” of clip into ram as shown. Twist “body” of clip
slightly so that second “arm” slides over the top of the first “arm”
as shown.
Push in direction indicated by arrows.
Push second “arm” back and into ram as shown.
Twist “body” of clip slightly again to spread “arms” of clip.
Clip “arms” must be flat and touching edge to edge as
shown, not overlapping.
A A
B B
C C
42
50
USE OF THIS PRODUCT
WITHOUT PROPER
INSTALLATION OF SMART
CLIPS
® , OR WHEN ALL
SMART CLIPS ® ARE NOT
PRESENT COULD RESULT
IN BODILY HARM. BE
SURE TO FOLLOW
DIRECTIONS CAREFULLY.
WARNING!
