42U Modular Storage Cabinet 50 Hz (Opal) 180312-B22
36U Modular Storage Cabinet 60 Hz (Opal) 180313-B21
36U Modular Storage Cabinet 50 Hz (Opal) 180314-B22
22U Modular Storage Cabinet 60 Hz (Opal) 180315-B21
22U Modular Storage Cabinet 50 Hz (Opal) 180316-B22
41U Modular Storage Cabinet 60 Hz (Blue) 180317-B21
41U Modular Storage Cabinet 50 Hz (Blue) 180318-B22
NOTE: Each Modular Storage Cabinet (42U, 41U, 36U, and 22U) comes with
redundant 220 to 240V PDUs and power cables to accommodate Modular Array
configurations. For more details on Modular Array solutions, see:
http://h18006.www1.hp.com/storage/arraysystems.html .
NOTE: xxxxxx-B21 (pallet) used to ship empty racks shipped on a truck. xxxxxx-
B22 (shock pallet) used to ship racks with equipment installed (by custom
systems, VARs and Channels). xxxxxx-B23 (crated) used for air shipments of
empty racks.
NOTE: It is mandatory to use a shock pallet in order to ship racks with
equipment installed.
NOTE: Please see the Rack 10000 QuickSpecs for additional part number and
Technical Specifications such as height, width, depth, weight, and color:
http://h18000.www1.hp.com/products/quickspecs/10995_div/10995_div.HTML
(Worldwide)
NOTE: For additional information regarding Rack Cabinets, please see the
following URL:
http://www.hp.com/go/rackandpower .
Legacy Racks
Supported Rack 7142 165753-001
Rack 9142 120663-B21
Rack 9136 120664-B21
Rack 9122 120665-B21
NOTE: Certain power support and cooling restrictions apply when housing a
maximum number of Model 4314R or Model 4354R enclosures in one of the
supported HP racks. Please refer to
http://h18006.www1.hp.com/storage/index.html for more information.
QuickSpecs HP StorageWorks Modular Smart Array 30 Single
Bus or Dual Bus Enclosures
Configuration Information
DA - 11738 Worldwide QuickSpecs — Version 25 — 6.8.2007 Page 9
