NOTE: Some of the options listed below may be discontinued.

Shipping Dimensions

Part Number

MSA30

34.38 x 34.375 x 12 in (87.33 x 87.313 x 30.48 cm) (SB)

302969-B21

34.38 x 34.375 x 12 in (87.33 x 87.313 x 30.48 cm) (DB)

302970-B21

Ultra320 Single Bus
Upgrade I/O Module

19.63 x 17.25 x 3.75 in (49.86 x 43.81 x 9.53 cm)

287484-B21

Ultra320 Dual Bus
Upgrade I/O Module

12.75 x 8 x 3.75 in (32.13 x 20.16 x 9.45 cm)

287483-B21

Redundant Power
Supply, 499 watts

12.75 x 8 x 3.75 in (32.13 x 20.16 x 9.45 cm)

338296-B21

Part Number

Controllers & Adapters
Supported

Smart Array 6404/256 Controller

273914-B21

(A9891A)

Smart Array 6402/128 Controller

273915-B21

(A9890A)

Smart Array 5304/256 Controller

283551-B21

(A9826A)

Smart Array 642 Controller

291967-B21

64-Bit/66Mhz Dual Channel Wide Ultra3 SCSI Adapter, Alternative OS

284688-B21

1 channel Ultra2 (LVD) Adapter (Alpha Server systems)

3X-KZPCA-AA

PCI-X TO SCSI UWD (FAST20 Differential) Adapter

3X-KZPBA-CC

NOTE: Requires: 3X-DWZCV-BA or 3X-DWZCV-CA HVD-to-LVD converter

1 Channel Wide Ultra-2 (LVD) Adapter

3X-KZPCA-AA

PCI to ULTRA3/LVD 2 Channel Host Bus Adapter

3X-KZPEA-DB

1 Channel, 64-BIT,PCI-U2 Backplane RAID Controller

DS-KZPCC-AC

3-Channel LVD 64 BIT PCI RAID Controller, 64MB Memory

DS-KZPCC-CE

Smart Array 5302A/128 for Alpha Systems

3X-KZPDC-BE

Smart Array 5304A/256 for Alpha Systems

3X-KZPDC-DF

PCI to 10/100MBPS Ethernet, Graphics, LVD SCSI Combo Adapter

3X-DEPVZ-AA

PCI-X Dual Channel U320 SCSI HBA
For configurations using the A7173A HBA, mixing disks (U160 and U320) is not
supported in the same MSA30 enclosure.

A7173A

PCI Dual Channel Ultra160 SCSI Adapter
OS Support: HP-UX 11i v1; HP-UX 11i v2.

A6829A

PCI Ultra160 SCSI Adapter
OS Support: HP-UX 11i v1; HP-UX 11i v2.

A6828A

PCI 2 Port 100Base-T & 2 Port Ultra2 SCSI
OS Support: HP-UX 11i v1; HP-UX 11i v2.

A5838A

Ultra160 SCSI Adapter
OS Support: Windows 2003 server on Integrity servers

A7059A

2 port Ultra160 SCSI HBA
OS Support: Windows 2003 server on Integrity servers

A7060A

QuickSpecs

HP StorageWorks Modular Smart Array 30 Single

Bus or Dual Bus Enclosures

Configuration Information

DA - 11738 Worldwide QuickSpecs — Version 25 — 6.8.2007

Page 7
