Technical specifications, Quickspecs – HP ProLiant DL165 User Manual
Page 27
System Unit
Dimensions
(H x W x D)
(with bezel)
1.70 x 17.64 x 26.85 in (4.32 x 44.80 x 68.20 cm)
Weight
(approximate)
Maximum
(all hard drives, power
supplies, and processors
installed)
37.00 lb (16.78 kg)
Minimum
(one hard drive, power
supply, and processor
installed)
30.00 lb (13.69 kg)
Input Requirements
(per 650W power
supply)
Rated Line Voltage
100-127 VAC,
200-240 VAC
Rated Input Current
10.0 A (at 115 VAC),
5.5 A (at 230 VAC)
Rated Input Frequency
47 to 63 Hz
Rated Input Power
852.16 W (at 100 VAC),
805.03W (at 200 VAC)
BTU Rating
Maximum
2217.89 BTU/hr (at 100 VAC),
2217.89 BTU/hr (at 200 VAC)
Power Specifications
To review typical system power ratings use the Power Calculator which
is available via the online tool located at URL:
- Click on the system of interest. Example: DL165 G5
- Follow the instructions of the next screens.
Power Supply Output
(per power supply)
Rated Steady-State Power 650 W (at 100 VAC),
650 W (at 200 VAC)
Maximum Peak Power
700 W (at 100 VAC),
700 W (at 200 VAC)
Optional High Efficiency Power Supply Specifications
Input Requirements
(per power supply)
Rated Line Voltage
90-132 VAC,
200-240 VAC
Rated Input Current
9.4 A (at 115 VAC),
7.8 A (at 230 VAC)
Rated Input Frequency
47 to 63 Hz
Rated Input Power
1075 W (at 100 VAC),
1375W (at 200 VAC)
BTU Rating
Maximum
3070.93 BTU/hr (at 100 VAC),
4094.57 BTU/hr (at 200 VAC)
Power Specifications
To review typical system power ratings use the Power Calculator which
is available via the online tool located at URL:
- Click on the system of interest. Example: DL165 G5
- Follow the instructions of the next screens.
Power Supply Output
(per power supply)
Rated Steady-State Power 900 W (at 100 VAC),
1200 W (at 200 VAC)
Maximum Peak Power
900 W (at 100 VAC),
1200 W (at 200 VAC)
QuickSpecs
HP ProLiant DL165 Generation 5
Technical Specifications
DA - 13015 Worldwide QuickSpecs — Version 5 — 5.23.2008
Page 27
