Hitachi SJ700-2 Series User Manual
Page 10
1 - 6
Default
Code
Function name
Monitored data or setting
_FF
_FEF
_FUF
Note
A081
AVR function select
00 (always on), 01 (always off), 02 (off during deceleration)
02
00
00
AV
R
A082
AVR voltage select
200 V class: 200, 215, 220, 230, 240 (V)
400 V class: 380, 400, 415, 440, 460, 480 (V)
200/400 230/400 230/460
A085
Operation mode selection
00 (normal operation), 01 (energy-saving operation), 02 (fuzzy operation) 00
A086
Energy saving mode tuning
0.1 to 100.0
50.0
A092
Acceleration (2) time setting
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
15.00
A292
Acceleration (2) time setting,
2nd motor
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
15.00
A392
Acceleration (2) time setting,
3rd motor
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
15.00
A093
Deceleration (2) time setting
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
15.00
A293
Deceleration (2) time setting,
2nd motor
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
15.00
A393
Deceleration (2) time setting,
3rd motor
0.01 to 99.99, 100.0 to 999.9, 1000. to 3600. (s)
15.00
A094
Select method to switch to
Acc2/Dec2 profile
00 (switching by 2CH terminal), 01 (switching by setting), 02 (switching only
when rotation is reversed)
00
A294
Select method to switch to
Acc2/Dec2, 2nd motor
00 (switching by 2CH terminal), 01 (switching by setting), 02 (switching only
when rotation is reversed)
00
A095
Acc1 to Acc2 frequency
transition point
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00
A295
Acc1 to Acc2 frequency
transition point, 2nd motor
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00
A096
Dec1 to Dec2 frequency
transition point
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00
A296
Dec1 to Dec2 frequency
transition point, 2nd motor
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00
A097
Acceleration curve selection
00 (linear), 01 (S curve), 02 (U curve), 03 (inverted-U curve), 04 (EL-S curve)
00
O
per
at
ion
m
ode and
acc
eler
at
ion/
deceler
at
ion
fu
nct
ion
A098
Deceleration curve setting
00 (linear), 01 (S curve), 02 (U curve), 03 (inverted-U curve), 04 (EL-S curve)
00
A101
[OI]-[L] input active range start
frequency
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00
A102
[OI]-[L] input active range end
frequency
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00
A103
[OI]-[L] input active range start
current
0. to "[OI]-[L] input active range end current" (%)
20.
A104
[OI]-[L] input active range end
current
"[OI]-[L] input active range start current" to 100. (%)
100.
A105
[OI]-[L] input start frequency
enable
00 (external start frequency), 01 (0 Hz)
00
A111
[O2]-[L] input active range start
frequency
-400. to -100., -99.9 to 0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00
A112
[O2]-[L] input active range end
frequency
-400. to -100., -99.9 to 0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00
A113
[O2]-[L] input active range start
voltage
-100. to 02 end-frequency rate (%)
-100.
Ext
er
nal f
requen
cy
adjus
tm
en
t
A114
[O2]-[L] input active range end
voltage
"02 start-frequency rate" to 100. (%)
100.
A131
Acceleration curve constants
setting
01 (smallest swelling) to 10 (largest swelling)
02
n and
deceler
at
io
A132
Deceleration curve constants
setting
01 (smallest swelling) to 10 (largest swelling)
02
A141
Operation-target frequency
selection 1
00 (digital operator), 01 (keypad potentiometer), 02 (input via O), 03 (input via
OI), 04 (external communication), 05 (option 1), 06 (option 2), 07 (pulse-string
frequency input)
02
A142
Operation-target frequency
selection 2
00 (digital operator), 01 (keypad potentiometer), 02 (input via O), 03 (input via
OI), 04 (external communication), 05 (option 1), 06 (option 2), 07 (pulse-string
frequency input)
03
A143 Operator
selection
00 (addition: A141 + A142), 01 (subtraction: A141 - A142), 02 (multiplication:
A141 x A142)
00
A145
Frequency to be added
0.00 to 99.99, 100.0 to 400.0 (Hz)
0.00
O
per
at
ion-
tar
ge
t f
requen
cy
A146
Sign of the frequency to be
added
00 (frequency command + A145), 01 (frequency command - A145)
00
A150
EL-S-curve acceleration
ratio 1
0. to 50. (%)
25.
A151
EL-S-curve acceleration
ratio 2
0. to 50. (%)
25.
A152
EL-S-curve deceleration
ratio 1
0. to 50. (%)
25.
Acceler
at
ion and
deceler
at
ion
A153
EL-S-curve deceleration
ratio 2
0. to 50. (%)
25.
