41
ABB/R (auto black balance/right) button
Direct mode :Black balance is adjusted automatically.
Menu mode :Execute or change function data.
AWB/L (auto white balance/left) button
Direct mode :White balance is adjusted automatically.
Menu mode :Execute or change function data.
Lock switch
Left position :Genlock (GL) adjustment
Right position :R/B gain and R/B black fine adjustment
Center position:Adjustments inoperative.
Select button
Lock switch left :Use together with the up/down buttons to select the following adjustments.
• H phase (horizontal phase)
• SC coarse (subcarrier coarse)
•
SC fine (subcarrier fine)
Lock switchright: n Use together with the up/down buttons to select the following adjustments.
• R gain
•
B gain
•
R black
• B black
Up ( ) and down ( ) buttons
Use together with the Lock switch and Select button to select the required adjustment
(corresponding LED lights).
BAR/CAM button
Selects the camera output signal.
• BAR: Color bar signal output
•
CAM: Camera video signal output
White BAL button
Selects the white balance mode.
• Auto: Real-time automatic tracking white balance
•
MEM: In the menu mode, press AWB/L for automatic white balance adjustment.
•
Preset: Optimum white balance at 3200 K color temperature
Gain button
Selects camera sensitivity mode.
•
18 dB: Maximum (+11 to +20 dB). In the menu mode, at the Sub menu 1 screen, set the Gain Max.
• 9 dB: High (+1 to +10 dB). In the menu mode, at the Sub menu 1 screen, set the Gain High.
• 0 dB: Normal mode
D (Option 1) button
Direct mode :Not used
Menu mode :Shift the cursor downward to select items from the displayed menu screen.
Setup (Option 2) button
Camera setting menu display button. Operations of buttons ABB/R , AWB/L and D differ when the menu
is displayed (menu mode) and not displayed (direct mode).
