Menu Screen Operation
1. Menu Structure
For settings in the camera, the MAIN and SPECIAL menus are available.
1-1 MAIN Menu Structure
Press the SEUTP button and MAIN MENU appears on the screen to indicate the main menu mode. Again press the
SETUP button to extinguish the menu and enter the direct mode. There are a main function setup menu and three
sub-menus, which are arranged hierarchically as shown below. On the MAIN menu, bring the cursor to SUB MENU
1, SUB MENU 2 or ALC and press the R button, and the desired subsidiary menu will come up. To return to the
MAIN menu from the SUB menu 1, SUB menu 2 or ALC, bring the cursor to the top line (title line of SUB MENU
1, SUB MENU 2or ALC) and press the L button.
On each menu screen, bring the cursor to any desired item using the U or D button. For mode change/data setting,
use the L or R button.
< SUB MENU1 (APP-1)
M.BLACK : 0
SHUTTER :OFF
VARIABLE :1/60.38
CCD MODE :FLD
DTL FREQ :STANDARD
GAIN HIGH :+ 9dB
GAIN MAX :+18dB
AGC :+20dB
< SUB MENU2 (APP-1)
DYNA CHROMA :OFF
CHROMA GAIN : 0
CONTRAST :OFF
KNEE :ON
AUTO KNEE :ON
MASKING :ON
GAMMA :ON
AUTO SHADING
WHITE GATE :OFF MESSAGE RTN :ON
R
L L
R
< MAIN MENU (APP-1)
CAM MODE :MANUAL
WHTE BAL :MEM 3200K
GAIN :NORMAL
ULTRA GAIN :OFF
DTL : 0
DNR :OFF
SUB MENU1 :->
SUB MENU2 :->
ALC :->
FILE INITIALIZE
< ALC
OVER RIDE : 0
IRIS GATE :OFF
R
L
SHAD MODE :COLOR
SPEED :STANDARD
At the first line of the main menu, press the R and L buttons to select the application file.
The indication changes to show the selected file.
Refer to Page 31 for a detailed description of the application file.
< MAIN MENU (APP-1)
Indication changes among
APP-1, APP-2 and APP-3
when the application file is
selected.
CAM MODE :MANUAL
WHTE BAL :MEM 3200K
GAIN :NORMAL
ULTRA GAIN :OFF
DTL
: 0
DNR :OFF
SUB MENU1 :->
SUB MENU2 :->
ALC
:->
FILE INITIALIZE
A P P - 1 A P P - 2 A P P - 3
L L R R
