Power Requirements Power Requirements Power Requirements Power Requirements NOTE: NOTE: NOTE: NOTE: Power system provides near unity power factor that allows full utilization of the input line current (Watts = VA).
NOTE: NOTE: NOTE: NOTE: The US/Canada model supports nominal input voltages of 115-117V. The Japan and Europe models support
nominal input voltages of 200-240V.
NOTE: NOTE: NOTE: NOTE: Fully configured system and one expansion cabinet consist of the above "fully configured system" and one
expansion cabinet that includes three PCI shelves, four storage shelves with a total of 24 disk drives.
GS80 Model 4 GS80 Model 4 GS80 Model 4 GS80 Model 4
U.S./Canada U.S./Canada U.S./Canada U.S./Canada Japan Japan Japan Japan Europe Europe Europe Europe
Nominal voltage(s) Nominal voltage(s) Nominal voltage(s) Nominal voltage(s) 120V 200 to 240V 220 to 240V
Frequency range Frequency range Frequency range Frequency range 50 to 60 Hz 50 to 60 Hz 50 to 60 Hz
Phases Phases Phases Phases 2 circuits 1 circuit 1 circuit
1-phase star 1-phase 1-phase
2-wire+ GND 2-wire+ GND 2-wire+ GND
Maximum input current/circuit Maximum input current/circuit Maximum input current/circuit Maximum input current/circuit 16A 13A 12A
Rating Rating Rating Rating 30A 30A 32A
Surge current Surge current Surge current Surge current 60A peak 160A peak 190A peak
Total Volt-Amps Total Volt-Amps Total Volt-Amps Total Volt-Amps 2600VA 2600VA 2600VA
Power cord length Power cord length Power cord length Power cord length 15 ft (4.5 m) 15 ft (4.5 m) 15 ft (4.5 m)
Power cap Power cap Power cap Power cap (system) 2 DEC 12-11193-00 1 DEC 12-16886-00 1 DEC 12-14379-07
Receptacle Receptacle Receptacle Receptacle (site) 2 DEC 12-11194-00 1 DEC 12-19658-01 1 Hubbell 332R6W
(industry equivalent) 2 NEMA L5-30R 1 NEMA L6-30R 1 IEC 309 (32A)
GS80 Model 8 GS80 Model 8 GS80 Model 8 GS80 Model 8
U.S./Canada U.S./Canada U.S./Canada U.S./Canada Japan Japan Japan Japan Europe Europe Europe Europe
Nominal voltage Nominal voltage Nominal voltage Nominal voltage(s) 120V 200 to 240V 220 to 240V
Frequency range Frequency range Frequency range Frequency range 50 to 60 Hz 50 to 60 Hz 50 to 60 Hz
Phases Phases Phases Phases 2 circuits 1 circuit 1 circuit
1-phase star 1-phase 1-phase
2-wire+ GND 2-wire+ GND 2-wire+ GND
Maximum input current/circuit Maximum input current/circuit Maximum input current/circuit Maximum input current/circuit 17A 20A 18A
Rating Rating Rating Rating 30A 30A 32A
Surge current Surge current Surge current Surge current 60A peak 200A peak 240A peak
Total Volt-Amps Total Volt-Amps Total Volt-Amps Total Volt-Amps 3900VA 3900VA 3900VA
Power cord length Power cord length Power cord length Power cord length 15 ft (4.5 m) 15 ft (4.5 m) 15 ft (4.5 m)
Power cap Power cap Power cap Power cap (system) 2 DEC 12-11193-00 1 DEC 12-16886-00 1 DEC 12-14379-07
Receptacle Receptacle Receptacle Receptacle (site) 2 DEC 12-11194-00 1 DEC 12-19658-01 1 Hubbell 332R6W
(industry equivalent) 2 NEMA L5-30R 1 NEMA L6-30R 1 IEC 309 (32A)
H9A20 I/O Expander Cabinet H9A20 I/O Expander Cabinet H9A20 I/O Expander Cabinet H9A20 I/O Expander Cabinet
Physical Characteristics Physical Characteristics Physical Characteristics Physical Characteristics Dimensions Dimensions Dimensions Dimensions
(H x W x D) 67 x 24 x 39.4 in (170 x 60 x 100 cm)
Shipping Dimensions Shipping Dimensions Shipping Dimensions Shipping Dimensions 76.5 x 44 x 48 in (195 x 92 x 122 cm)
Weight Maximum Weight Maximum Weight Maximum Weight Maximum
Configuration
Configuration Configuration Configuration
1,349 lb (613 kg)
Shipping Weight Shipping Weight Shipping Weight Shipping Weight
Maximum Configuration
Maximum Configuration Maximum Configuration Maximum Configuration
1,635 lb (743 kg)
QuickSpecs
HP AlphaServer GS80 (1224 MHz)
TechSpecs
DA - 11422 North America — Version 7 — August 19, 2003 Page 40
