Processor Processor Processor Processor Up to eight Alpha 21264 6/1224-MHz CPUs (one CPU per module)
Cache Memory Cache Memory Cache Memory Cache Memory 64-K I and D caches on-chip; 16-MB ECC on-board cache per CPU
Architecture Architecture Architecture Architecture AlphaServer GS80 utilizes a modular crossbar switch structure
AlphaServer GS80 uses either one or two system drawers as building blocks. Each drawer houses a Quad building block
(QBB) system module, which supports up to four CPUs, four memory modules, and eight PCI buses on a 7-GB/s non-
blocking backplane switch
Up to two system drawers are connected by a direct internal interconnect with 3.3-GB/s of bandwidth
CPUs, Memory, and I/O CPUs, Memory, and I/O CPUs, Memory, and I/O CPUs, Memory, and I/O
Slots
Slots Slots Slots
Base systems contain one CPU and one master PCI I/O drawer
Model 4 Model 4 Model 4 Model 4 Model 8 Model 8 Model 8 Model 8
Maximum CPUs supported 4 8
Maximum memory supported 32 GB (4 modules) 64 GB (8 modules)
Maximum PCI slots supported 28 56
NOTE: NOTE: NOTE: NOTE: Model 4 and Model 8 base systems include 12 configurable PCI slots. System capacities shown are available
with both Tru64 UNIX and OpenVMS operating systems.
Network and I/O Network and I/O Network and I/O Network and I/O
Controllers
Controllers Controllers Controllers
Ethernet PCI Dual 10/100 Mbit Fast Ethernet adapter (DE602) included in master PCI shelf box; additional
Ethernet adapters available as options
Console ports One bi-directional parallel port with 25-pin D-subminiature connector
Two EIA-232 full duplex asynchronous modem control serial ports, 9-pin
D-subminiature connectors
One PS/2 compatible keyboard port; one PS/2 compatible mouse port
Boot/Diagnostic Devices Boot/Diagnostic Devices Boot/Diagnostic Devices Boot/Diagnostic Devices Boot/diagnostic devices included in master PCI shelf box
CD-ROM One 5.25-inch half height 600-MB CD-ROM drive
Hard Drives One 18.2-GB 10,000 rpm SCSI disk drive
Internal Disk Expansion Internal Disk Expansion Internal Disk Expansion Internal Disk Expansion Total Internal Drive Bays Up to 14 146-GB drives (2,044 GB) can be mounted in one optional storage shelf in the
system cabinet
Power Supplies Power Supplies Power Supplies Power Supplies Single-phase power subsystem with power cords; optional redundant 48 VDC hot swap power supplies
QuickSpecs
HP AlphaServer GS80 (1224 MHz)
Standard Features
DA - 11422 North America — Version 7 — August 19, 2003 Page 2
