Service Reference Guide, dc5750 437963-001 A–7
Connector Pin Assignments
SATA Data and Power
Drive Connector
Pin Signal Pin Signal Pin Signal Pin Signal
S1
S5 Ground
B- S2
S6 A+
B+ S3
S7 A-
Ground S4 Ground
P1
P5
P9
P13 V 3.3
Ground
V 5
V 12 P2
P6
P10
P14 V 3.3
Ground
Ground
V 12 P3
P7
P11
P15 V 3.3
V 5
Reserved
V 12 P4
P8
P12 Ground
V 5
Ground
*S = Data, P = Power
