ENGLISH
29
No.
Signal mode
Horizontal
frequency (kHz)
Dot clock
frequency (MHz)
Remarks
Signal Name Resolution
Vertical
frequency (Hz)
1
VGA
640 X 400 70.08 31.47 25.18
2 640 X 480 59.94 31.47 25.18
3
VESA
640 X 480 72.81 37.86 31.50
4 640 X 480 75.00 37.50 31.50
5 640 X 480 85.01 43.27 36.00
6 800 X 600 56.25 35.16 36.00
7 800 X 600 60.32 37.88 40.00
8 800 X 600 72.19 48.08 50.00
9 800 X 600 75.00 46.88 49.50
10 800 X 600 85.06 53.67 56.25
11 1024 X 768 60.00 48.36 65.00
12 1024 X 768 70.07 56.48 75.00
13 1024 X 768 75.03 60.02 78.75
14 1024 X 768 85.00 68.68 94.50
15 1280 X 1024 60.02 63.98 108.00
16 1280 X 1024 75.03 79.98 135.00
17 1280 X 1024 85.02 91.15 157.50
18 1600 X 1200 60.00 75.00 162.00
19 1600 X 1200 75.00 93.75 202.50
20 1600 X 1200 85.00 106.25 229.50
21
Macintosh
640 X 480 66.67 35.00 30.24
22 832 X 624 74.55 49.73 57.28
23 1024 X 768 75.11 60.24 80.00
24 1152 X 870 75.06 68.68 100.00
25 1080 / 60i 1080i 59.94 33.72 -
H/V separate
sync only
■ The following are recommended for use with this moniter (RGB input):
Recommended Signal List
• The type of video board or connecting cable used may not allow for correct displays adjustment of
H.POSITION, V.POSITION, CLOCK and PHASE.
• The monitor may fail to display an animation image correctly when a signal having a vertical frequency
of 85Hz or higher is input to it.
• The monitor differentiates the signal modes according to the horizontal and vertical frequencies and the
horizontal and vertical sync signal polarities. Note that different signals having all these elements alike
may be handled as the same signal.
• Displaying images with more than 512 lines of vertical resolution at Full diplay (compressed display) can
result in the interpolation of stripes.
• Use of this monitor with the input signal timings specified below is recommended. A predefined setting
may not be reproduced correctly with an extremely long front porch or back porch or with an extremely
short data display time.
Front porch Sync width Back porch Blanking width
Horizontal
timing
Horizontal frequency
24 kHz to 52 kHz
0.2 µs or more 1.0-4.0 µs 1.2 µs or more 3.5 µs or more
Horizontal frequency
52 kHz to 106 kHz
0.2 µs or more 0.8-3.0 µs 1.1 µs or more 2.3 µs or more
Vertical timing 9 µs or more 25 µs or more 400 µs or more 450 µs or more
