Index
Maintenance and Service Guide Index–3
modem jack
location 1–15 , 1–17
pin assignments B–6
monitor port
location 1–15 , 1–17
pin assignments B–3
monitor stand port 1–14 , 1–16
mouse connector
location 1–14 , 1–16
pin assignments B–4
MultiBay II 1–11
dummy card 3–5
light 1–11
problems 2–6
N
network jack
location 1–15 , 1–17
pin assignments B–6
O
optical drive problems 2–6
P
packing precautions 4–3
parallel port
location 1–14 , 1–17
pin assignments B–5
parts list 3–1
plastic parts 4–2
power button 1–7 , 1–9 , 1–10 ,
1–11
power connector 1–15 , 1–17
power cord
set requirements C–2
spare part number 3–3 , 3–6
power light 1–7 , 1–9 , 1–10 ,
1–11 , 1–15 , 1–17
preliminaries
removal 4–1
replacement 4–1
troubleshooting checklist
2–2
R
rear panel components 1–14 ,
1–16
removal and replacement
procedures 5–1
right-side components 1–12 ,
1–13
RJ-11 jack
location 1–15 , 1–17
pin assignments B–6
RJ-45 jack
location 1–15 , 1–17
pin assignments B–6
rubber bumper, spare part
number 3–5
rubber feet, spare part number
3–5
S
screw listing A–1
security cable slot 1–14 , 1–16
serial number 3–1 , 5–1
serial port
location 1–15 , 1–17
pin assignments B–7
service considerations 4–1
spare part number
advanced docking station
3–3 , 3–6
