Maintenance and Service Guide Index–1
Index
A
AC adapter, spare part number
3–3 , 3–6
advanced docking station
spare part number 3–3 , 3–6
specifications 6–3
See also docking station
audio-in jack
location 1–15 , 1–17
pin assignments B–1
audio-out jack
location 1–14 , 1–16
pin assignments B–2
B
bumper, spare part number
3–5
C
cable lock bezel blank, spare
part number 3–5
cable lock bezel, spare part
number 3–5
cable lock slot 1–12 , 1–13
cables, service considerations
4–2
components
left-side 1–10 , 1–11
rear panel 1–14 , 1–16
right-side 1–12 , 1–13
top 1–6 , 1–8
composite video jack 1–15 ,
1–17
computer eject button 1–7 ,
1–9 , 1–12 , 1–13
computer eject mechanisms
1–7 , 1–9
connection troubleshooting
2–2 , 2–3
connector pin assignments
audio-in jack B–1
audio-out jack B–2
external monitor port B–3
headphone jack B–2
keyboard connector B–4
microphone jack B–1
modem jack B–6
monitor port B–3
mouse connector B–4
network jack B–6
parallel port B–5
