2-8 Mini Controller User’s Manual
Audio Rate or Intensity Manipulation
Within each audio parameter, there are nine functions for Program, Rate
and Intensity manipulation. These functions are annotated as
0 through 9 on
the display. Refer to Table 2.3 and the Addendum for the purpose of these
functions.
Note: Audio Function 9 will override Standby Mode when used with a Lightning
Program.
Table 2.4: Audio Rate or Intensity Manipulation Functions
Function
Number
Manipulation of Rate or Intensity
0 no manipulation
1 frame advancing on beat
2 four frames advance per beat
3 beat causes maximum Rate, otherwise Rate
equals medium
4 beat causes maximum Rate, otherwise Rate
taper down
5 maximum Intensity on beat, then Intensity
tapers down
6 minimum Intensity on beat, then Intensity
tapers up
7 Intensity flips between maximum and medium
on beat
8 maximum Intensity on beat, otherwise medium
Intensity
9 resets program to first step on beat
