10. BBWC Battery Pack 12. Fan 4
11. Power Supply Backplane 13. T-15 Torx screwdriver
12. PCI-Express x8 non-hot-plug expansion slot 1 14. Redundant power supply 4 - 6 (optional)
13. PCI-Express x4 non-hot-plug expansion slot 2 15. Power supply 1 - 3
14. PCI-Express x4 non-hot-plug expansion slot 3
15. PCI-Express x4 non-hot-plug expansion slot 4
16. PCI-Express x16 non-hot-plug expansion slot 5
17. PCI-Express x4 non-hot-plug expansion slot 6
18. PCI-Express x4 non-hot-plug expansion slot 7
19. Serial Peripheral Interface (SPI) Board
20. System Maintenance Switch
21. Fan 1
22. Fan 2
23. Fan 3
Not shown: PCI-Express expansion slots 8 - 11
At A Glance At A Glance At A Glance At A Glance
The HP ProLiant DL785 G5, the newest and most expandable addition to the award winning HP ProLiant line, is an 8-socket x86
server, supporting up to 8 AMD Opteron™ Quad-Core processors, 256 GB of memory and 11 PCI-e I/O slots. With this highly
scalable feature set the DL785 G5, is an ideal choice for the growing enterprise class database, consolidation and virtualization
environments seeking to improve server utilization and reduce server sprawl, while continuing to leverage all the familiar and easy to
use ProLiant management tools and options.
Processors Processors Processors Processors:
Supports up to 8 Quad-Core AMD 8300 Series Processors
Memory Memory Memory Memory:
Up to 256 GB of memory, supported by 64 slots of PC2-5300 Registered DIMMs
Storage Controller Storage Controller Storage Controller Storage Controller:
HP Smart Array P400i Controller
Optional 256MB and 512MB battery backed write cache
Internal Drive Support Internal Drive Support Internal Drive Support Internal Drive Support:
Support for up to 8 hot plug SFF SAS drives, standard
Optional SAS Option Kit available to support an additional 8 hot plug SFF SAS drives, for a total of 16 internal drives
Optional Slimline DVD/CD-RW drives
Network Controller Network Controller Network Controller Network Controller:
Two embedded NC371i Multifunction Gigabit Network Adapters with TCP/IP Offload Engine, including support for
Accelerated iSCSI through an optional Licensing Kit
Expansion Slots Expansion Slots Expansion Slots Expansion Slots:
11 total slots: (3) x16 PCI-Express; (3) x8 PCI-Express; (5) x4 PCI-Express
Video Ports Video Ports Video Ports Video Ports:
One front and one rear video ports
USB Ports USB Ports USB Ports USB Ports:
(5) Total USB 2.0 Ports: (2) front; (2) rear; (1) internal
Redundancy Redundancy Redundancy Redundancy:
Redundant hot plug power supplies and fans
Management Management Management Management:
Integrated Lights-Out 2 featuring Integrated Remote Console with KVM over IP performance over shared network
QuickSpecs
HP ProLiant DL785 Generation 5 (G5) HP ProLiant DL785 Generation 5 (G5) HP ProLiant DL785 Generation 5 (G5) HP ProLiant DL785 Generation 5 (G5)
Overview
DA - 13046 Worldwide — Version 4 — May 21, 2008 Page 2
